Traveling Wave Tube Amplifiers (TWTAs)

S/C Band TWTAs

Specifications: 4-8 GHz, 3.7 kW pulsed, 6% duty cycle, rackmount configuration.

Applications:
radars, ECM, EW threat simulation, test and measurement, antenna pattern and radar cross-section measurements

Download Datasheet

Specifications: 2-6 GHz, 325 Watts CW, rackmount configuration.

Applications: ECM transmitters, EW simulation, test and measurement, RFI susceptibility testing, EMC tests

Download Datasheet

I/J Band TWTAs

Specifications: 8-18 GHz, 2 kW pulsed, 5% duty cycle, rackmount configuration.

Applications: Radars, ECM, EW threat simulation, test and measurement, antenna pattern and radar cross-section measurements

Download Datasheet

Specifications:  6-18 GHz, 200 Watts CW.

Applications: ECM, EW simulation, multi-band communication systems.

Download Datasheet

Specifications:  6-18 GHz, 300 Watts CW, rackmount configuration.

Applications:  ECM transmitters, EW simulation, test and measurement, RFI susceptibility testing, EMC tests, RF components testing, antenna pattern and radar cross-section measurements.

Download Datasheet

Specifications:  7.5-18 GHz, 300 Watts CW.

Applications:  Airborne data links, electronic countermeasures (ECM), EW simulation, manned and unmanned platforms.

Download Datasheet

X Band TWTAs

Specifications: 8-12 GHz, 8 kW peak, 5% duty cycle, podmount configuration.

Applications: Airborne radar, electronic warfare (EW) threat simulation

Download Datasheet

Specifications:  8-12 GHz, 4 kW peak, 8% duty cycle, rackmount configuration.

Applications: Radars, ECM, EW threat simulation, test and measurement, antenna pattern and radar cross-section measurements

Download Datasheet

Ku Band TWTAs

Specifications: 12-18 GHz, 3.3 kW peak, 6% duty cycle, rackmount configuration.

Applications: Radars, ECM, EW threat simulation, test and measurement, antenna pattern and radar cross-section measurements

Download Datasheet

Ka Band TWTAs

Specifications: 34.5-35.5 GHz, 700 Watts peak, 10% duty cycle, hubmount configuration.

Applications: Radars, test/measurement, antenna pattern and radar cross-section measurements, EW simulation

Download Datasheet

Specifications:  34.5-35.5 GHz, 700 Watts pulsed, 10% duty cycle, hubmount configuration.

Applications: ECM, Radars, test/measurement, antenna pattern and radar cross-section measurements, EW simulation.

Download Datasheet

Specifications:  34.5-35.5 GHz, 750 Watts peak, 10% duty cycle, rackmount configuration.

Applications:  Radars, test/measurement, antenna pattern and radar cross-section measurements, EW simulation.

Download Datasheet

Specifications:  34.5-35.5 GHz, 700 Watts peak, 10% duty cycle, rackmount configuration, color touchscreen interface.

Applications:  Radars, test/measurement, antenna pattern and radar cross-section measurements, EW simulation.

Download Datasheet

Specifications:  32-36 GHz, 400 Watts peak, 25% duty cycle, rackmount configuration.

Applications:  Radars, test/measurement, antenna pattern and radar cross-section measurements, EW simulation.

Download Datasheet

Power Combined TWTAs

Specifications: 8-2-4 GHz, 10 kW pulsed, 6% duty cycle.

Applications: Test and measurement, RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation.

Download Datasheet

Specifications:  4-8 GHz, 8 kW pulsed, 6% duty cycle.

Applications: Test and measurement, RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation.

Download Datasheet

Specifications:  8-12 GHz, 9 kW pulsed, 6% duty cycle.

Applications: RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation.

Download Datasheet

Specifications:  12-18 GHz, 7 kW pulsed, 6% duty cycle. Applications: RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation. Download Datasheet
Specifications:  5.4-5.8 GHz, 12 kW pulsed, 3% duty cycle. Applications: RFI/Test and measurement, RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation. Download Datasheet

Specifications:  9-10 GHz, 12 kW pulsed, 6% duty cycle.

Applications: RFI/Test and measurement, RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation.

Download Datasheet

Specifications:  2.9-3.3 GHz, 15 kW pulsed, 6% duty cycle.

Applications: RFI/Test and measurement, RFI/EMI/EMC testing, antenna pattern and radar cross-section measurements, ECM, EW simulation.

Download Datasheet

Specifications:  7.5-18 GHz, 3.4/4 kW pulsed, 6% duty cycle. Applications: RFI/Test and measurement, RFI/EMI/EMC testing, Antenna pattern and radar cross-section measurements, ECM, EW simulation. Download Datasheet

Microwave Power Modules (MPMs)

Standard MPMs

Specifications: 26.5 – 40 GHz, 125 Watts pulsed to CW.

Applications: ECM, EW simulation

Download Datasheet

Specifications:  27.5 – 31 GHz, 200 Watts CW. Applications: Satellite communications, datalink communications. Download Datasheet

Specifications:  9-10 GHz, 1 kW pulsed.

Applications:  Multi-mode radars, SAR, manned and unmanned platforms.

Download Datasheet

Specifications:  6-18 GHz, 1 kW pulsed, 5% duty cycle.

Applications:  High-performance EW.

Download Datasheet

Specifications:  6-18 GHz, 200 Watts pulsed to CW.

Applications:  ECM, EW simulation, multi-band communication systems.

Download Datasheet

Specifications:  6-18 GHz, 200 Watts pulsed to CW. Prime input voltage 115 VAC, 400 Hz. Applications:  ECM, EW simulation, multi-band communication systems. Download Datasheet

Specifications:  6-18 GHz, 100 Watts pulsed to CW, Ethernet interface.

Applications:  ECM, EW simulation.

Download Datasheet

High-Efficiency MPMs

Specifications:  9-10 GHz, 1 kW pulsed, 20% duty cycle.

Applications:  High-performance radar, high-resolution synthetic aperture radar (SAR) systems, manned and unmanned platforms

Download Datasheet

Power Supplies & Towed Decoys

Specifications: DC-to-DC converter, +1500VDC to +10VDC at 43Amps.

Download Datasheet

Specifications:  1500VDC Input, 6.4VDC Output at 68Amps.

Download Datasheet
